Solar Street Light - LED Based Solar Street Light

Solar street light system is an ideal application for campus and village street lighting. The system is provided with battery storage backup sufficient to operate the light for 10-11 hours daily. Automatic ON/OFF time switch for dusk to down operation and overcharge / deep discharge prevention cut-off are provided with LED indicators. Easy Photovoltech's solar street lightening systems require low maintenance, have longer life and provide better performance. We manufacture and supply two types of solar street light i.e. solar LED street lights, solar CFL street light.

LED Based Solar Street Light
Key Features :

• PWM MOSFET based solar charge controller for efficient battery charging
• 100% short circuit protection
• Surge/lightning protected.
• Perfect design, Easy Installation
• Automatic dawn dusk operation (with timer-optional)
• Highly Economic and reliable. (Optional)
• Single Battery Typet
• Temperature Compensated Battery charging.
• Approved by MNRE Govt, of India
• Excellent for remote villages
• Low maintenance
• High reliability and durability
• More intensity of light
• CC-CV output with APMS Technology (Optional)

Luminary Type NT2014-08 NT2014-012 NT2014-024
Output Light Intensity 15Lux @ 4m 25Lux @ 6m 30Lux @ 6m
Nominal Power 9W 14W 26W
Efficiency >90% >90% >90%
Battery 40Ah Tubular 100Ah Tubular 100Ah Tubular
No. of LEDs 08Nos 12Nos 24Nos
SPV 45WP 75WP 120WP
Self Consumption <7ma <7ma <7ma
Nominal Battery Voltage 12V 12V 24V
Max Module Current 5A 8A 6A
Charging Method CC-CV
Charge Control PWM
Display Indication LED (Low Battery, Charging)
Indication Battery charging, Low Battery, Battery Overcharge
Pole 15Ft/20Ft Optional
Luminary Degree of Protection IP65
Cooling Natural Air Cooled
Ambient Temperature -20°C to +50°C
